5 Inch RTSP Face Scanner Attendance System Door Entry Access Control
Face recognition terminal with 5 inch screen,which is designed to organize access control by identifying biometric features of a person's face and / or reading the identifier using a reader connected to the RFID device.
Main Features:
1. Face recognition,up to 10,000 face users
2. Support mask detection
3.Work with RFID,connect the reader through wiegand in
4. White LED light for night vision
5. Configuration via the web interface
6. Free provide HTTP API / MQTT for integration
Product Advantages:
1. Our own developed face tracking exposure algorithm(linear mode),WDR≥110DB
2. Hardware&software customerized service,protect customer own design and confidential data
3. Adopted own top-class face recognition algorithm, spent 6 years jointly developed by Russian mathematicians and top China scientist, face recognition accuracy(night version) is high than 99%, recognized speed less than 0.3 seconds.
Technical specification:
| Model | B2002FR-5I-WM-L06 |
| Hardware | |
| Processor | Made in China Dual-core+1G memory+8G EMMC |
| Operating system | Linux Operating system |
| Storage | Support TF card storage |
| Camera | Two cameras,effective pixels,1920 * 1080 |
| Sensor | 1/2.8" Progressive Scan CMOS |
| Lens | 6mm |
| Swipe card module | Under Planning |
| Wifi module | Optional |
| Bluetooth module | Optional |
| Performance | |
| Recognition height | 1.2~2.2 meters,Angle can be adjusted |
| Recognition distance | 0.5~1.5 meters,depends on lens |
| Face angle | 30 degrees left and right, 30 degrees up and down |
| Recognition time | Less than 0.5 second |
| Capture capacity | 60,000 capture records |
| Face capacity | 10,000 |
| Interface | |
| Power input | DC12V/2A |
| Network Interface | 1x RJ45 10M / 100M Adaptive Ethernet port |
| Wiegand Interface | 1ch Wiegand interface input/output |
| Camera | |
| Camera | Two cameras,all-glass lens,visible light and near-infrared,supports live detection |
| Effective pixels | 2.1MP effective pixels,1920*1080 |
| Minimum illumination | Color 0.01Lux @F1.2(ICR);black white 0.001Lux @F1.2 (ICR) |
| SNR | ≥50db(AGC OFF) |
| WDR | 120db, ISP algorithm |
| Video encoding | H.265 Main Profile/H.264 BP/MP/HP/MJPEG |
| Dual stream Resolution | Main Stream | 50Hz: 25fps (1920×1080,1280×720) |
| | | 60Hz: 30fps (1920×1080,1280×720) |
| | Sub Stream | 720*576,1-25(30)fps/s/640*480,1-25(30)fps/s 320*240,1-25(30)fps/s |
| Regular | |
| Operating temperature | -30℃ - +60℃ |
| Working humidity | 0 ～ 90% relative humidity, non-condensing |
| Power | 10W(MAX) |
| Salt fog level | Rp6 or higher |
| Antistatic | Contact ± 6KV, Air ± 8KV |
| Power supply | DC12V/2A |
| Protection class | IP54 |
| Screen Size | 5 inch HD IPS screen |
| Size | 205(L) * 95(W) *20(H)mm |
FAQ:
Q: Do you sell at retail?
A: Sorry,we are factory and it’s need technical person to install it,so we are not sell to personal user directly,thanks.
Q: Do you provide SDK/API for secondary development?
A: Of course,customized service is our advantage.We could provide SDK/HTTP/MQTT(integrate cloud) for integration.included firmware customization.
Q: What's the MOQ of product?
A: 1PC for the sample order;After tested sample order,the MOQ is 10pcs/Model.
Q: What are your terms of payment?
A: We accept Paypal,Western Union and TT before production.
Q: Could you provide OEM/ODM for customers?
A: Sure,we provide full OEM&ODM service,Like Logo printed,carton box design ect.Our engineer could design the OSD menu as request.If for more questions,welcome to contact us for further discussion,thanks.
Q: What's the delivery time?
A: Sample order about 2-7 working days;Normal order about 6-12 working days;Bulk order can about 10-25 working days.It's depend on the quantities.
Q: What's the warranty and support?
A: All the goods be checked before dispatch.We provide 2 years warranty after the shipment date.
We have professional technical support team to support our customers,and if you have any question for the technology of our products,please email or chat with us by skype,thank you in advance.
